15.6″ T-MOM
Touch Monitor
Made of Brand New Original Parts, <>Meeting Industrial-Grade Dtandards.
Provides 5-Year Free Warranty and Supports Free OEM Service.
Display
Brand New TFT-LCD, WLED Backlight Screen.
Stable Quality and Longer Life.

15.6" TN

TFT LCD PCAP Touch

HD 1366*768

Resolution

a-Si TFT-LCD

Panel Type

220 cd/m² (Typ.)

Display Brightness

45/45/20/40

(Typ.)(CR≥10) Viewing Angle

500:1 (Typ.)

Contrast

Capacitive

Multi-Touch Screen

7H

Hardness Glass on PCAP Touch

16 : 9

Screen Ratio

15,000

MTBF over 15,000 Hours

Display
Brand New TFT-LCD, WLED Backlight Screen.
Stable Quality and Longer Life.

15.6" TN

TFT LCD PCAP Touch

FHD 1920*1080

Resolution

a-Si TFT-LCD

Panel Type

220 cd/m² (Typ.)

Display Brightness

45/45/20/40

(Typ.)(CR≥10) Viewing Angle

500:1 (Typ.)

Contrast

Capacitive

Multi-Touch Screen

7H

Hardness Glass on PCAP Touch

16 : 9

Screen Ratio

15,000

MTBF over 15,000 Hours

Display
Brand New TFT-LCD, WLED Backlight Screen.
Stable Quality and Longer Life.

15.6" IPS

TFT LCD PCAP Touch

FHD 1920*1080

Resolution

a-Si TFT-LCD

Panel Type

220 cd/m² (Typ.)

Display Brightness

85/85/85/85

(Typ.)(CR≥10) Viewing Angle

800:1 (Typ.)

Contrast

Capacitive

Multi-Touch Screen

7H

Hardness Glass on PCAP Touch

16 : 9

Screen Ratio

15,000

MTBF over 15,000 Hours

Capacitive Touch Screen
Industrial 10-point Touch Capacitive Touch Screen, Not Afraid of
Water and oil.
Control Panel
It is Placed on The Back of The Display and
Supports Brightness Adjustment/Hue/Color
Temperature Adjustment.
Standard VESA
Provides Flexible Installation Options, Standard VESA (75mm*75mm ) Interface.
Split Bracket
The split bracket design greatly saves transportation costs.
Free OEM
Screen LOGO/Body LOGO/Boot LOGO/Box LOGO/
Label LOGO all Support Free Options.
5 Years Free Warranty
POS / MPC / PPC / Monitor Devices Can Enjoy
up to 5 Years Free Warranty.
