K2 11.6″ MINI POS
Made of Brand New Original Parts, Meeting Industrial-Grade Dtandards.
Provides 5-Year Free Warranty and Supports Free OEM Service.
Display
Brand New TFT-LCD, WLED Backlight Screen.
Stable Quality and Longer Life.

11.6" TN

TFT LCD PCAP Touch

HD 1366*768

Resolution

a-Si TFT-LCD

Panel Type

220 cd/m² (Typ.)

Display Brightness

45/45/20/40

(Typ.)(CR≥10) Viewing Angle

500:1 (Typ.)

Contrast

Capacitive

Multi-Touch Screen

7H

Hardness Glass on PCAP Touch

16 : 9

Screen Ratio

15,000

MTBF over 15,000 Hours

Display
Brand New TFT-LCD, WLED Backlight Screen.
Stable Quality and Longer Life.

11.6" IPS

TFT LCD PCAP Touch

FHD 1920*1080

Resolution

a-Si TFT-LCD

Panel Type

220 cd/m² (Typ.)

Display Brightness

80/80/80/80

(Typ.)(CR≥10) Viewing Angle

1000:1 (Typ.)

Contrast

Capacitive

Multi-Touch Screen

7H

Hardness Glass on PCAP Touch

16 : 9

Screen Ratio

15,000

MTBF over 15,000 Hours

Optional Processor
Intel® Celeron® / Intel® Core™ i3 / Intel® Core™ i5 / Intel® Core™ i7
AMD Ryzen™ R2000 Series
Rockchip® RK3288 / RK3566 / RK3568 / RK3399
Qualcomm® Snapdragon™ 625 / Snapdragon™ 660
Operating System
Support Windows, Android, Linux and Other
Operating System.

Supported Versions

Windows 7

Windows 8

Windows 10

Windows 10 IOT

Windows 11

Supported Versions

Android 5.1

Android 7.1

Android 9.0

Android 11

Android 13

Supported Versions

ubuntu

CentOS

More Linux OS

Capacitive Touch Screen
Industrial 10-point Touch Capacitive Touch Screen, Not Afraid of
Water and oil.
Quick Installation MSR
Quickly Install the MSR & NFC Card Reader by Yourself
According to Your Needs.
(Optional Function)
iButton Support
Support iButton (Dallas key) Function.
(Optional Function)
I/O Panel
Supports Customization of More I/O Options.
Standard VESA
Provides Flexible Installation Options, Standard VESA (75mm*75mm) Interface.

Click and drag to rotate, scroll to zoom, or swipe and pinch on touch devices to explore the model.

Free OEM
Screen LOGO/Body LOGO/Boot LOGO/Box LOGO/
Label LOGO all Support Free Options.
5 Years Free Warranty
POS / MPC / PPC / Monitor Devices Can Enjoy
up to 5 Years Free Warranty.
